RGH 3000 gas spring

• Shortest length gas spring
• Body diameter is same as ISO type – from 45 mm to 120 mm
• Force : from 500 daN to 5000 daN
• Stroke : from 6 mm to 125 mm
• Can be used in piping system

Print this sheet
RGH 3000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 2
RGH 3000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 3
RGH 3000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 4
Type Force Stroke C Reference Pressure Force F1 Force F2 LR LC Mass
daN mm MPa (bar) N* N* mm mm Kg
RGH 3000 25 442761/000 15

(150)

29 460 43 250 120 95 4.20
38.1 442762/000 43 520 146.2 108.1 4.40
50 442763/000 43 450 170 120 4.60
63.5 442764/000 43 410 197 133.5 4.80
80 442765/000 43 620 230 150 5.10
100 442766/000 43 690 270 170 5.40

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order: RGH 3000 C50
Spare Kit : 896522/000.
Composition : Guide ring, seals, valve and lubricant.

RGH 3000 gas spring : LOW PROFILE RGH GAS SPRINGS - Quiri - 5
