Single acting cylinders – Spring return – 700 bar – SRS

Steel

Features

  • Single acting cylinder, spring return
  • Body, rod and lock-nut in sulphonitrided steel
  • Full load mechanical stop
  • Supplied as standard with HF738
  • Supplied with tilting saddle

Notes

Cylinders SRS545 and SRS5410 supplied with carrying handles
Cylinders SRS5415 to SRS9325 supplied with eye hooks

Print this sheet
Single acting cylinders – Spring return – 700 bar – SRS : Lifting steel cylinders 700 bar - Quiri - 2
Cylinder category Maximum force at 700 bar Stroke Effective area Oil volume Reference Dimensions Mass
Tons kN mm cm2 cm3 a b b’ c d e f h i j k m n o q M x p sur øg kg
23 232.26 50 33.18 165.9 SRS 235 65 184 207 182 85 83.3 21 22 70 54×5 39 12 2 25 54 2 x 1/2 13 UNC on ø59 Depth: 26 7.2
100 331.8 SRS 2310 240 263 238 8.8
150 497.7 SRS 2315 279 302 277 9.5
200 663.6 SRS 2320 329 352 327 11
250 829.5 SRS 2325 379 402 377 12.5
31 309.4 150 44.2 663 SRS 3115 75 277 298 274 100 100 25 26 70 2″1/4×5 39 12 3 24 54 13.1
54 549.78 50 78.50 392.7 SRS 545 100 174 199 172 130 129 31 28 70 80×5 60 13 2 27 60 4xM10x15 sur ø115 16
100 785.4 SRS 5410 225 250 223 19
150 1178.1 SRS 5415 285 310 283 23.7
93 929.11 100 132.73 1327.3 SRS 9310 130 249 277 246 175 174 36 26 70 105×5 94 12 3 31 93 40
150 1991.0 SRS 9315 297 327 296 47.4
250 3318.3 SRS 9325 436 464 433 47 65
