Extra flat cylinders with safety nut – 700 bar – SSP

Steel

Features
Notes

Features

• Single acting with gravity return
• Body, rod and safety nut in sulphonitrided steel
• Stroke-limiting port prevents accidental piston extension
• Supplied as standard with HF738 coupling
• Integral swivel head, up to 5° depending on model,
• Robust design accepts up to 10% radial load,
• see table below

Notes

Ensure that the bottom of the cylinder is fully supported when in use.

Print this sheet

Extra flat cylinders with safety nut – 700 bar – SSP : Lifting steel cylinders 700 bar - Quiri - 2

Cylinder category	Maxi. force 700 bar	Stroke	Head angle of inclination	Maximum radial load resistance	Effective area	Oil volume	Reference	Dimensions (mm)									Weight
Cylinder category	Maxi. force 700 bar	Stroke	Head angle of inclination	Maximum radial load resistance	Effective area	Oil volume	Reference	a	b	d	f	h	i	j	k	o	Weight
Tons	kN	mm	°	%	cm2	cm3		a	b	d	f	h	i	j	k	o	kg
35	351.7	45	5	10	50	226	SSP 35	80	125	105	22	15.5 with 7° angle	70	M80 x 4	66	5	8.5
60	605.8	45	5	10	87	389	SSP 60	105	121	140	24	19.5 with 6° angle	70	M105 x 4	96	7	14
100	1001.5	45	5	10	143	644	SSP 100	135	132	173	28	26.5	70	M135 x 4	126	8	24
150	1588.1	45	5	8	227	1021	SSP 150	170	68	220	36	27.5	70	M170 x 4	160	10	43
200	1983.7	45	5	8	283	1275	SSP 200	190	154	245	38	29.5	70	M190 x 4	180	10	55
250	2540.1	45	5	5	363	1633	SSP 250	215	157	275	35	32.5	70	M215 x 4	200	13	70
400	4005.9	45	4	5	572	2575	SSP 400	270	177	350	42	38.5	70	M270 x 4	252	13	129
500	4945.5	45	3	5	707	3179	SSP 500	300	190	400	47	42.5	70	M300 x 4	290	11	182
