Single acting cylinders, load return, high tonnage – 700 bar – SGL

Steel

Features

Features

• Single acting, load return
• Fitted with removable grooved saddle
• Chrome plated piston rod
• Fitted in standard with HF 738 coupler
• 2 transport eye hooks

Print this sheet

Single acting cylinders, load return, high tonnage – 700 bar – SGL : Lifting steel cylinders 700 bar - Quiri - 2

Cylinder category	Maximum force 700 bar	Stroke	Effective area	Oil volume	Reference	Dimensions (mm)												Weight
						a	b	b’	c	d	h	i	j	k	m	n	o
Tons	kN	mm	cm2	cm3														kg
200	1983,7	50	283,53	1417	SGL2005	190	219	266	212	242	62	70	150	113	13	5	52	70,8
		150		4252	SGL20015		319	366	312									95,3
300	3034,6	150	433,74	6506	SGL30015	235	371	437	361	302	78	70	170	130	25	5	71	183
		250		10843	SGL30025		481	547	471									234
400	4005,9	150	572,5	8590	SGL40015	270	381	466	372	349	88	70	210	160	25	5	90	259
		240		13741	SGL40024		481	566	472									314
500	5111,8	150	730,62	10960	SGL50015	305	400	500	391	392	91	70	240	180	25	5	105	343
		190		13882	SGL50019		450	550	441									367
