RGT 4200 gas spring

• Diameter from 32 to 150 mm
• Stroke from 10 to 125 mm
• Force : from 350 to 9500 daN (9.5t)
• Designed especially for car makers
• Solid design (no welding)
• Design and features similar to RGP but can be used with standard G 1/8’’ piping system (except RGT 350)
• Long bottom threads recommended for fixtures with screws in the upper die
• Conforms to Toyota standard : SMS DNH 3203 N

Print this sheet
RGT 4200 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 2
RGT 4200 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 3
RGT 4200 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 4
RGT 4200 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 5
Type Force

daN

Stroke C

mm

Order code Pressure

MPa (bar)

Force F1

N*

Force F2

N*

LR

mm

LC

mm

Weight

Kg

RGT 4200 16 443664/000-S 15

(150)

(!)

42 420 62 890 94 78 3,30
19 443665/000-S 63 870 100 81 3,40
25 443666/000-S 65 610 112 87 3,60
32 443667/000-S 66 790 126 94 3,80
38 443668/000-S 67 670 138 100 3,90
50 443669/000-S 68 770 162 112 4,20
63 443670/000-S 69 520 188 125 4,60
75 443671/000-S 70 020 212 137 4,90
80 443672/000-S 70 170 222 142 5,00
100 443673/000-S 70 700 262 162 5,50
125 443674/000-S 71 960 312 187 6,20

* (N) = Kgf x 9.80665 | (Kgf)=N x 0.101972 | 1daN=1 x 101N | 1bar=1 x 10-1MPa

Example of order : RGT 4200 C50
Spare Kit : 896534/000
Composition : Guide ring, seals, valve and lubricant.

RGT 4200 gas spring : HIGH POWER RGT GAS SPRINGS - Quiri - 6

(!) There is a blue sticker on the gas spring body when it is inflated with a special pressure (<15 MPa)
