Hydraulic block cylinders – BDE AG Type

Test pressure: 500 bars
Max working pressure: 350 bars

Feeding ports at the top left side.
Fixture perpendicular to the rod.
Key provided
Seal kits on stock

  • Key groove (key provided)
  • Solid body, burnished bore
  • Solid piston rod
  • Strokes ± 0,3mm
  • Guiding improved on piston and rod
Print this sheet
Hydraulic block cylinders – BDE AG Type : Hydraulic block cylinders BDE - Quiri - 2
TYPE Units BDE 25 BDE 32 BDE 40 BDE 50 BDE 63 BDE 80 BDE 100 BDE 125
Piston ø (mm) 25 32 40 50 63 80 100 125
Rod ø (mm) 16 20 25 32 40 50 63 80
Pushing force at 100 bars (kN) 4.9 8.0 12.5 19.6 31.1 50.2 78.5 122.7
Pulling force at 100 bars (kN) 2.9 4.9 7.7 11.6 18.6 30.6 47.4 72.4
a (mm) 65 75 85 100 125 160 200 230
b (mm) 45 55 63 75 95 120 150 180
c (mm) 7 10 10 10 14 14 15 16
e (mm) 10.5 12 12 12 17.5 17.5 17.5 17.5
f (mm) 50 55 63 76 95 120 158 180
g (mm) 8.5 10.5 10.5 13 17 21 25 32
g1 x depth (mm) ø14 x 9 ø17 x 11 ø17 x 11 ø20 x 13 ø25 x 17 ø32 x 21 ø38 x 25 ø47 x 30.5
h (mm) 33 38 40 44 50 60 64 82
j H8 (mm) 10 12 12 16 20 24 28 35
k (mm) 22.5 27.5 31.5 37.5 47.5 60 75 90
n (mm) 15 16.2 20 21.5 19.5 26 27 40.5
p G1/8 G1/4 G1/4 G1/4 G1/2 G1/2 G1/2 G1/2
z (mm) 2 3 4 5 6 7 8 9
z’ (+0.1 0) (mm) 6 5 4 5 6 7 8 9
Stroke(C)<=130 mm
Body length (L) (mm) C+44 C+50 C+54 C+65 C+72 C+85 C+90 C+110
Between feeding holes (m) (mm) C+18 C+23 C+23 C+31 C+36 C+38 C+38 C+39
Stroke(C)>130 mm
Body length (L) (mm) C+58.5 C+66 C+70 C+86 C+90 C+106 C+108 C+137
Between feeding holes (m) (mm) C+21 C+26 C+26 C+34 C+40 C+42 C+42 C+43
Between fixing holes (h1) (mm) C-14 C-19 C-18.5 C-13.5 C-22.5 C-28 C-32 C-40
Minimum stroke (mm) 15 20 20 20 25 30 35 45
Maximum stroke (mm) 200 250 300 350 350 400 400 400
3D Model 3D 3D 3D 3D 3D 3D 3D 3D

Rod ends

Hydraulic block cylinders – BDE AG Type : Hydraulic block cylinders BDE - Quiri - 3
TYPE Units BDE 25 BDE 32 BDE 40 BDE 50 BDE 63 BDE 80 BDE 100 BDE 125
ød (mm) 16 20 25 32 40 50 63 80
B (mm) 5.8 7.5 8.5 9 12.2 12 12 13
C (mm) M10 x 1.5 M12 x 1.75 M16 x 2 M20 x 2.5 M27 x 3 M30 x 3.5 M42 x 4.5 M48 x 5
øD (mm) 10.5 12.5 16.5 21 28 31 43 49
øE (mm) 15.2 19 24 31 39 49 61.5 78
K (mm) 13 17 22 27 36 46 55 70
L (mm) 18 22 28 36 45 52 60 64
M (mm) M14 x 1.5 M16 x 1.5 M20 x 1.5 M27 x 2 M33 x 2 M39 x 2 M45 x 2 M52 x 2
P (mm) 18 18 25 30 40 40 60 70
Q (mm) 4 4 7 7 10 10 10 10

Options

TYPE Units BDE 25 BDE 32 BDE 40 BDE 50 BDE 63 BDE 80 BDE 100 BDE 125
TA (mm) M8 x 12 M10 x 15 M10 x 15 M12 x 18 M16 x 24 M20 x 30 M24 x 36 M30 x 45
LI (mm) 8.5 10.5 10.5 13 17 21 25 32
