Hydraulic block cylinders – BDE F2 Type

Test pressure: 500 bars
Max working pressure: 350 bars

Feeding holes at the front.
Fixture parallel to the rod.
Seals kits are available on stock

  • Key groove (key provided)
  • Solid body, burnished bore
  • Solid piston rod
  • Strokes ± 0,3mm
  • Guiding improved on piston and rod
Print this sheet
Hydraulic block cylinders – BDE F2 Type : Hydraulic block cylinders BDE - Quiri - 2
TYPE Units BDE 25 BDE 32 BDE 40 BDE 50 BDE 63 BDE 80 BDE 100 BDE 125
Piston ø (mm) 25 32 40 50 63 80 100 125
Rod ø (mm) 16 20 25 32 40 50 63 80
Pushing force at 100 bars (kN) 4.9 8.0 12.5 19.6 31.1 50.2 78.5 122.7
Pulling force at 100 bars (kN) 2.9 4.9 7.7 11.6 18.6 30.6 47.4 72.4
a (mm) 65 75 85 100 125 160 200 230
b (mm) 45 55 63 75 95 120 150 180
c (mm) 7 10 10 10 14 14 15 16
g (mm) 8.5 10.5 10.5 13 17 21 25 32
g1 x depth (mm) ø14 x 9 ø17 x 11 ø17 x 11 ø20 x 13 ø25 x 17 ø32 x 21 ø38 x 25 ø47 x 30.5
k (mm) 22.5 27.5 31.5 37.5 47.5 60 75 90
s (mm) 50 55 63 76 95 120 158 180
t (mm) 30 35 40 45 65 80 108 130
øv (mm) 4 5 5 6 8 8 8 8
øw x depth (mm) 10.8 x 1.1 10.8 x 1.1 10.8 x 1.1 12.7 x 1.3 14.2 x 1.3 14.2 x 1.3 17.5 x 2 17.5 x 2
ød1 x depth (mm) 3 x 6 3 x 6 5 x 10 6 x 10 8 x 10 10 x 10 10 x 15 12 x 15
x1 (mm) 8 9 10 11 15 18 25 28
y1 (mm) 29 33 37 44 55 70 90 102
TA (mm) M8 x 12 M10 x 15 M10 x 15 M12 x 18 M16 x 24 M20 x 30 M24 x 36 M30 x 45
Stroke(C)<=130 mm
Body length (L) (mm) C+44 C+50 C+54 C+65 C+72 C+85 C+90 C+110
Stroke(C)>130 mm
Body length (L) (mm) C+58.5 C+66 C+70 C+86 C+90 C+106 C+108 C+137
Maximum stroke (mm) 200 250 300 350 350 400 400 400
3D Model 3D 3D 3D 3D 3D 3D 3D 3D

Rod ends

Hydraulic block cylinders – BDE F2 Type : Hydraulic block cylinders BDE - Quiri - 3
TYPE Units BDE 25 BDE 32 BDE 40 BDE 50 BDE 63 BDE 80 BDE 100 BDE 125
ød (mm) 16 20 25 32 40 50 63 80
B (mm) 5.8 7.5 8.5 9 12.2 12 12 13
C (mm) M10 x 1.5 M12 x 1.75 M16 x 2 M20 x 2.5 M27 x 3 M30 x 3.5 M42 x 4.5 M48 x 5
øD (mm) 10.5 12.5 16.5 21 28 31 43 49
øE (mm) 15.2 19 24 31 39 49 61.5 78
K (mm) 13 17 22 27 36 46 55 70
L (mm) 18 22 28 36 45 52 60 64
M (mm) M14 x 1.5 M16 x 1.5 M20 x 1.5 M27 x 2 M33 x 2 M39 x 2 M45 x 2 M52 x 2
P (mm) 18 18 25 30 40 40 60 70
Q (mm) 4 4 7 7 10 10 10 10

Options

WARNING:

For cylinders of this type, with strokes >130mm, the 4 smooth mounting holes parallel to the rod are automatically replaced by 4 tapped holes (TA) on the feed face.

TYPE Units BDE 25 BDE 32 BDE 40 BDE 50 BDE 63 BDE 80 BDE 100 BDE 125
TA (mm) M8 x 12 M10 x 15 M10 x 15 M12 x 18 M16 x 24 M20 x 30 M24 x 36 M30 x 45
LI (mm) 8.5 10.5 10.5 13 17 21 25 32
