Long clamping arm – rod with taper: 1:10 – For swing clamp size: 15 – 25 – 35 – 45 BLK

For swing clamp size: 15 - 25 - 35 - 45
Rod end with 1:10 taper

Characteristics

• adjustable over 360°
• burnished surface

Maximum force (and thus maximum pressure) decreases proportionally with clamping arm extension. Maximum flow rate also decreases with the inertia of the clamping arm. For standard arms, please note the values stated in the table. (see ULT charts).

The rod must absolutely be held while clamping;
see figure 1 on the guide

Print this sheet

Long clamping arm – rod with taper: 1:10 – For swing clamp size: 15 – 25 – 35 – 45 BLK : Swing clamps with helical rotation - Quiri - 2

Tap	Bevel	Type	Reference
Tap	Bevel	Type	Reference	a	b	c	ød 0/- 0.05	e	f	g	h	k	øl
				mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
WITH	WITH	BLK 15	811 330/000	105	32	80	20	18	16	M10	20	4	24
WITH	WITH	BLK 25	811 331/000	160	48	120	32	24	25	M16	32	5	34
WITH	WITH	BLK 35	811 332/000	195	60	150	40	30	30	M16	40	5	46
WITH	WITH	BLK 45	811 333/000	248	78	190	50	42	40	M20	50	6	56

See similar accessories

Clamping arm for swing clamp: P5 BP5

for swing clamp: H5

Short clamping arm – rod with 15° taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BC

for swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 15° taper

Short clamping arm – rod with 1:10 taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BCK

For swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 1:10 taper

Medium clamping arm – rod with 15° taper – For swing clamp size: 11 – 12 – 21 – 31 – 41 BM

For swing clamp size: 11 - 12 - 21 - 31 - 41
rod end with 15° taper
