Medium clamping arm – rod with taper: 1:10 – For swing clamp size: 15 – 25 – 35 – 45 BMK

For swing clamp size: 10 - 15 - 20 - 25 - 35 - 45
Rod end with 1:10 taper

Characteristics

• adjustable over 360°
• burnished surface

Maximum force (and thus maximum pressure) decreases proportionally with clamping arm extension. Maximum flow rate also decreases with the inertia of the clamping arm. For standard arms, please note the values stated in the table. (see ULT charts).

The rod must absolutely be held while clamping;
see figure 1 on the guide

Print this sheet

Medium clamping arm – rod with taper: 1:10 – For swing clamp size: 15 – 25 – 35 – 45 BMK : Swing clamps with helical rotation - Quiri - 2

Tap	Bevel	Type	Reference
Tap	Bevel	Type	Reference	a	b	c	ød 0/- 0.05	e	f	g	h	k	øl
				mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
WITH	WITH	BMK 10	811 362/000	58	28	35	16	14	16	M8	17	2.5	20
WITH	WITH	BMK 15	811 322/000	75	32	50	20	18	16	M10	16	4	24
WITH	WITH	BMK 20	811 361/000	93	45	60	25	23	22	M12	26	4	31
WITH	WITH	BMK 25	811 323/000	115	48	75	32	24	25	M16	23	5	34
WITH	WITH	BMK 35	811 324/000	140	60	95	40	30	30	M16	28	5	46
WITH	WITH	BMK 45	811 325/000	178	78	120	50	42	40	M20	34	6	56
