Short clamping arm – rod with taper: 1:10 – For swing clamp size: 15 – 25 – 35 – 45 BCK

For swing clamp size: 15 - 25 - 35 - 45
Rod end with 1:10 taper

Characteristics

• adjustable over 360°
• burnished surface

Maximum force (and thus maximum pressure) decreases proportionally with clamping arm extension. Maximum flow rate also decreases with the inertia of the clamping arm. For standard arms, please note the values stated in the table. (see ULT charts).

The rod must absolutely be held while clamping;
see figure 1 on the guide

Print this sheet

Short clamping arm – rod with taper: 1:10 – For swing clamp size: 15 – 25 – 35 – 45 BCK : Swing clamps with helical rotation - Quiri - 2

Tap	Bevel	Type	Reference
Tap	Bevel	Type	Reference	a	b	c	ød 0/- 0.05	e	f	h	k	øl	m	n	p
				mm	mm	mm		mm	mm	mm	mm	mm	mm	mm	mm
WITHOUT	WITH	BCK 15	811 334/000	51.5	32	33.5	20	14	16	15.5	3.5	24	21	14.5	7
WITHOUT	WITH	BCK 25	811 335/000	76	46	50	32	25	23	22.5	4.5	34	28	19	7
WITHOUT	WITH	BCK 35	811 336/000	100	66	64	40	39	33	28	5	46	34	23	7
WITHOUT	WITH	BCK 45	811 337/000	123	75	82.5	50	39	37.5	34	6	56	40	27	8

See similar accessories
