Block with supply through tapped port
Double-acting - with rotation travel
Force at 500 bar: 6.5 to 42 kN
Block with supply through tapped port
• clamping arm: see accessories section
• 60°, 45° or 0° angle of rotation on request
• special models on request
• Rod with indexing
Definition of forces depending on clamping arm: see below
Important recommendations: consult the guide
Force with
500 bar |
Force with
350 bar |
clamping travel | rotation travel | total travel | Section
A B |
Swept volume
A B |
Direction of rotation | Indexation | Type | Reference | ||||||||||||
a1
|
a2
|
ød
|
e
|
k
|
l
|
øm
|
n1
|
n2
|
øo
|
øo1
|
p
|
|||||||||||
kN | kN | mm | mm | mm | cm2 | cm3 | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | mm | |||||
6.5 | 4.62 | 7 | 7 | 14 | 1.76
4.9 |
2.47
6.86 |
right | WITHOUT | UBT 15 | 191 255/000 | 65 | 45 | 20 | M18 x 1.5 | 71 | 110 | 3 | 50 | 30 | 8.5 | 14.5 | 63 |
WITH | 191 255/050 | |||||||||||||||||||||
left | WITHOUT | 191 255/100 | ||||||||||||||||||||
WITH | 191 255/150 | |||||||||||||||||||||
17 | 11.76 | 8 | 8 | 16 | 4.52
12.56 |
7.23
20.10 |
right | WITHOUT | UBT 25 | 191 261/000 | 85 | 63 | 32 | M28 x 1.5 | 91 | 139 | 4 | 63 | 40 | 10.5 | 17.5 | 81 |
WITH | 191 261/050 | |||||||||||||||||||||
left | WITHOUT | 191 261/100 | ||||||||||||||||||||
WITH | 191 261/150 | |||||||||||||||||||||
42 | 30.24 | 11 | 9 | 20 | 11.53
31.17 |
23.06
62.34 |
right | WITHOUT | UBT 45 | 192 234/000 | 125 | 95 | 50 | M45 x 1.5 | 110 | 175 | 4 | 95 | 65 | 17 | 25.5 | 94 |
WITH | 192 234/050 | |||||||||||||||||||||
left | WITHOUT | 192 234/100 | ||||||||||||||||||||
WITH | 192 234/150 |
