Hydraulic units for pullers

Capacity
(Tons)		 Reference Composition Weight
Hollow piston cylinder Cylinder hollow saddle Hand pump Pressure gauge Adaptor Hose
10 UH 10 CSE 124 TTC 12 PMS 7105* MG 1220 AM 135 FC 032 11
20 UH 20 CSE 204 TTC 20 PMS 7105* MG 1220 AM 135 FC 032 16
30 UH 30 CSE 296 TTC 29 PMS 7105* MG 2958 AM 135 FC 032 21
50 UH 50 CSE 587 TTC 58 PMS 722* MG 2958 AM 135 FC 032 37

* It is possible to substitute the hand pump by air hydraulic pump (see Air hydraulic pumps – foot operated and Air hydraulic pumps) or a 2 speeds PMS 733 hand pump (see Single acting hand pumps, 2 speeds)
